Mitsubishi GOT1000 GT15 User Manual

2.2 Component List
2.2.2 Option
2 - 15
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
PART NAME AND SETTINGS
5
EMC AND LOW VOLTAGE DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
Connection cables for ALLEN-BRADLEY PLCs (Sold separately)
Connection cables for SIEMENS PLCs (Sold separately)
RS-422 conversion unit (Sold separately)
Bus extension connector box (Sold separately)
Bus connector conversion box (Sold separately)
CF card (Sold separately)
*2: Some models with the operations checked by our company are usable.
For the validated models, refer to Technical News GOT-A-0010 "List of Valid Devices Applicable for GOT1000
Series" separately available, or contact your local distributor.
Product
name
Model name Description
RS-232
cable
GT09-C30R20701-9S Cable length 3m For connecting GOT to ALLEN-BRADLEY PLC
Product
name
Model name Description
RS-232
cable
GT09-C30R20801-9S Cable length 3m For connecting GOT to SIEMENS HMI Adapter
Product name Model name Description
RS-422 conversion
unit
GT15-RS2T4-9P
RS-232 RS-422
conversion unit
RS-422 side connector 9 pins
GT15-RS2T4-25P RS-422 side connector 25 pins
Product name Model name Description
Bus extension
connector box
A9GT-QCNB
For QCPU (Q Mode)/Motion controller CPU (Q series) long distance
(13.2m or longer) bus connection
Product name Model name Description
Bus connector
conversion
box
A7GT-CNB
For QnA/ACPU/Motion controller CPU (A series) long distance bus
connection (For conversion from large type connector to small type
connector)
Product name Model name Description
CF card
GT05-MEM-16MC Flash ROM 16MB
GT05-MEM-32MC Flash ROM 32MB
GT05-MEM-64MC Flash ROM 64MB
GT05-MEM-128MC Flash ROM 128MB
GT05-MEM-256MC Flash ROM 256MB
GT05-MEM-512MC Flash ROM 512MB
GT05-MEM-1GC Flash ROM 1GB
GT05-MEM-2GC Flash ROM 2GB
Commercially-available CF card
*2

Mitsubishi GOT1000 GT15 Specifications

General

Display Size	10.4 inches
Display Type	TFT Color LCD
Resolution	640 x 480 pixels
Touch Panel Type	Analog resistive film
Power Supply	24V DC
Backlight	LED
Protection Rating	IP65 (front panel)
Interface	RS-232, RS-422/485, USB
Operating Temperature	0°C to 50°C
Memory	9 MB
Storage Temperature	-20 to 60°C
Display Colors	256 colors
