3.2 Performance Specifications
3.2.3 GT1575V-S, GT1575-S, GT1575-V, GT1575-VN, GT1572-VN
3 - 11
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
SPECIFICATIONS
4
PART NAME AND
SETTINGS
5
EMC AND LOW
VOLTAGE
DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
*1 Bright dots (always lit) and dark dots (unlit) may appear on a liquid crystal display panel due to its characteristics.
It is impossible to completely avoid this symptom, as the liquid crystal display comprises of a great number of
display elements. Please note that these dots appear due to its characteristic and are not caused by product
defect.
*2 With the hardware version indicated below, it will be 256 colors when the multi-color display board is not installed.
For how to confirm the function version, refer to the following.
Appendix Confirming of Versions and Conformed Standards
*3 The GOT screen saving/backlight off function prevents images from becoming permanently etched on the display
screen and increases the backlight life.
*4 ROM in which new data can be written without deleting the written data.
*5 Compliant with IP67 when the USB environmental protection cover is attached. Compliant with IP2X at the USB
interface only when a USB cable is connected. Note that this does not guarantee all users' operation
environment.
In addition, the GOT may not be available for use in the environment where oil or chemicals are splashed over for
a long period or where oil mist is filled.
Item
Specifications
GT1575V-STBA,
GT1575V-STBD
GT1575-STBA,
GT1575-STBD
GT1575-VTBA,
GT1575-VTBD
GT1575-VNBA,
GT1575-VNBD,
GT1572-VNBA,
GT1572-VNBD
External dimensions
(Excluding USB environmental
protective cover)
303(11.93)(W) 214(8.43)(H) 49(1.93)(D)[mm](inch)
Panel cutting dimensions 289(11.38)(W) 200(7.87)(H)[mm](inch)
Weight
2.3 kg(5.1lb)
(mounting fixtures are
not included)
2.4 kg(5.3lb)
(mounting fixtures are not included)
2.3 kg(5.1lb)
(mounting fixtures
are not included)
Compatible software package
GT Designer3
Version1.01B or later
GT Designer2
Version2.32J or later
GT1575-STBA:
GT Designer3
Version1.01B or
later
GT Designer2
Version2.04E or
later
GT1575-STBD:
GT Designer3
Version1.01B or
later
GT Designer2
Version2.17T or
later
GT1575-VTBA:
GT Designer3
Version1.01B or
later
GT Designer2
Version2.04E or
later
GT1575-VTBD:
GT Designer3
Version1.01B or
later
GT Designer2
Version2.17T or
later
GT Designer3
Version1.01B or
later
GT Designer2
Version2.17T or
later
Item Model Function version
GT1575
GT1575-STBA A
GT1575-STBD A
GT1575-VTBA A
GT1575-VTBD A
