3.2 Performance Specifications
3.2.5 GT1555-V, GT1555-Q, GT1550-Q
3 - 17
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
SPECIFICATIONS
4
PART NAME AND
SETTINGS
5
EMC AND LOW
VOLTAGE
DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
Item
Specifications
GT1555-VTBD GT1555-QTBD GT1555-QSBD GT1550-QLBD
Human
sensor
Detection
temperature
None
Memory
*3
C drive Built-in flash memory 9Mbytes (for string project data and OS)
Life (Number of write
times)
100,000 times
Battery GT15-BAT lithium battery (Option)
Backup target Clock data and maintenance time notification data
Life Approx. 5 years (Operating ambient temperature of 25°C)
Built-in
interface
RS-232
*5
RS-232, 1ch
Transmission speed: 115,200/57,600/38,400/19,200/9,600/4,800 bps
Connector shape: D-sub 9-pin (Male)
Application: For communicating with a controller or connecting a personal computer (Project data read/
write, OS installation and FA transparent function)
USB
USB (Full Speed 12 Mbps), Device, 1ch
Connector shape: Mini-B
Application: For connecting a personal computer (Project data read/write, OS installation and FA
transparent function)
CF card
Compact flash slot, 1ch
Connector shape: TYPE 1
Application: Data transfer, data storage, GOT startup
When formatting a CF card to FAT16: Up to 2GB
When formatting a CF card to FAT32: Not available
Option function board For option function board mounting, 1ch
Extension unit
*5
For communication unit/option unit mounting, 1ch
Buzzer output Single tone (tone length adjustable)
Protective structure
Outside the enclosure: IP67
*4
Inside the enclosure: IP2X
External dimensions
(Excluding USB environmental
protective cover)
167(6.6)(W) 135(5.3)(H) 56(2.2)(D)[mm](inch)
Panel cutting dimensions 153(6.0)(W) 121(4.8)(H)[mm](inch)
Weight 1.1 kg(2.4lb) (mounting fixtures are not included)
Compatible software package
GT Designer3 Version1.01B
or later
GT Designer2 Version2.58L
or later
GT Designer3 Version1.01B or later
GT Designer2 Version2.32J or later
To Next Page
