4.2 Part Names and Settings of the GT1585
4 - 5
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
PART NAME AND SETTINGS
5
EMC AND LOW VOLTAGE DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
Connector used for the RS-232 interface
The specification of the connector used for the RS-232 interface of GT1585 is as
follows.
GOT model name Hardware version Connector
GT1585V-STBA A (March, 2006) or later Manufacturer: DDK Ltd.
Model name: 17LE-23090-27 (D4CK) or equivalent
product
GT1585V-STBD A (May, 2006) or later
GT1585-STBA
B (April, 2005) or before
Manufacturer: Honda Tsushin Kogyo Co., Ltd.
Model name: GM-C9RMDU11 or equivalent product
C (April, 2005) or later Manufacturer: DDK Ltd.
Model name: 17LE-23090-27 (D4CK) or equivalent
product
GT1585-STBD A (July, 2005) or later

Mitsubishi GOT1000 GT15 Specifications

General

Display Size	10.4 inches
Display Type	TFT Color LCD
Resolution	640 x 480 pixels
Touch Panel Type	Analog resistive film
Power Supply	24V DC
Backlight	LED
Protection Rating	IP65 (front panel)
Interface	RS-232, RS-422/485, USB
Operating Temperature	0°C to 50°C
Memory	9 MB
Storage Temperature	-20 to 60°C
Display Colors	256 colors
