Chapter 4: USB Setup Interface
36
Acceleration Setup Object [AccelSetup; ObjId=34]
StartMinFlow Inst Start min. Flow
TempCoefOffset Inst reserved
TempCoefGain Inst reserved
SpeedupGain Inst Speedup Gain
SpeedupTau Inst Speedup Tau
SpeedupGainFlowInc Inst Speedup Gain Flow Increment
SpeedupGainTempInc Inst Speedup Gain Temp Increment
SpeedupTauTempInc Inst Speedup Tau Temp Increment
TempValveOffset Inst
Add Valve Offset addicted to Temperature (TempValveOffset * Calibration
TempDif)
FltType Inst [no Filter, Filter1, Filter2]
Flt1StabFac Inst Stabilization Factor for Filter 1
Flt1ReactFac Inst Reactivation Factor for Filter 1
Flt2Boarder Inst Filter Boarder for Filter 2
Digits Inst define the resolution
AddValveOffset Inst Add Valve Offset
SetDefault Func Reset object to default values
Gas Conversion Object [GasConv; ObjId=35]
Name
Par.
Type
Description
Instance Inst Show the Instance of the Object
ID Inst Name of the conversion e.g. gas name
CalTableInstance Inst Reference to the CalTable which linearizes the flow signal
ControllerSetupInstance Inst Reference to the ControllerSetup which define the PID settings
AccelSetupInstance Inst Reference to the AccelSetup which define the speedup settings
GasCorrectionFactor Inst Factor for translating the linearized gas type to the wanted
FullScale Inst FullScale derived from physical by the GCF and Meter - FlowUnit
MinDisplay Inst define zero for relative outputs [in Meter - FlowUnit] e.g. %, ‰, V
MaxDisplay Inst define FullScale for relative outputs [in Meter - FlowUnit] e.g. %, ‰, V
SetDefault Func Reset object to default values
Device Status Object [Status; ObjId=36]
Name
Par.
Type
Description
ExceptionByte Inst reserved
CommonExceptionDetailAlarm Inst
bit0 = reserved
bit1 = TripPointHigh2Alarm
bit2 = TripPointLow2Alarm
bit3 - bit7 = reserved
DeviceExceptionDetailAlarm Inst bit0 = an USB error occurred
ManufacturerExceptionDetailAlarm Inst reserved
CommonExceptionDetailWarn Inst
bit0 = CalibrationRecommended
bit1 = TripPointHighAlarm
bit2 = TripPointLowAlarm
