Chapter 4: USB Setup Interface
37
Device Status Object [Status; ObjId=36]
bit3 = ControllerError
bit4 - bit7 = reserved
DeviceExceptionDetailWarn Inst reserved
ManufacturerExceptionDetailWarn Inst
bit0 = an power fail occurred
bit1 = an setpoint overflow occurred
bit2 = an flow value overflow occurred
bit3 - bit7 = reserved
AlarmEnable Inst
[disable, enable]
Enable diagnostics if an error alarm status has changed
WarningEnable Inst
disable, enable]
Enable diagnostics if an warning alarm status has changed
EepromChecksumFailCnt Inst Counter for Eeprom checksum fail errors
FlashChecksumFailCnt Inst Counter for flash checksum fail errors
StartUpCnt Inst Counts the startups
LowVoltageCnt Inst Counter for low voltage errors
WpdCnt Inst Counter for set device password
WpfCnt Inst Counter for set factory password
WdSibCnt Inst Counter for SIB watchdogs
SibDibComExcepCnt Inst Counter for SIB<=>DIB communication lost
WdDibCnt Inst Counter for DIB watchdogs
SetDefault Func Reset object to default values
Analog Interface Object [Analog; ObjId=37]
Name
Par.
Type
Description
OperationMode Inst [Analog, Digital] sets the inputs to analog or digital mode
FullscaleVoltage Inst output Voltage if GasConf - MaxDisplay is reached
ZeroscaleVoltage Inst output Voltage if GasConf - MinDisplay is reached
SetDefault Func Reset object to default values
Fieldbus Interface Object [Fieldbus; ObjId=38]
Name
Par.
Type
Description
Address Inst configured address
SoftwareAddress Inst if software address is < 126 this address is used for fieldbus
MaxBaudrate Inst Shows the maximum Profibus baud rate
CyclTlgInputObjectId Inst Id of last used cyclic input telegram
CyclTlgOutputObjectId Inst Id of last used cyclic output telegram
Config Inst reserved
SetDefault Func Reset object to default values
RestartFieldBus Func restart RestartFieldBus
