Moons' M2 Series User Manual

M Series AC Servo
User Manual
21
Rev. 1.0
7/31/2019
400-820-9661
2.4 Servo Drive and Servo Motor Combinations
AC Servo Motor
Specificatioon
50W 100W 200W 400W 750W
Motor Model Numbers
2500ppr Increment
Encoder
(9PIN AMP connector)
Without Brake
SM0401AE4-KCD-
NNV09
SM0402AE4-KCD-
NNV09
SM0601AE4-KCD-
NNV09
SM0602AE4-KCD-
NNV09
SM0803AE4-KCD-
NNV09
With Brake
SM0401AE4-KCD-
BNV09
SM0402AE4-KCD-
BNV09
SM0601AE4-KCD-
BNV09
SM0602AE4-KCD-
BNV09
SM0803AE4-KCD-
BNV09
Rated Speed
(RPM) 3000
Maximum Speed
(RPM) 6000
Rated Torque
(N•m) 0.19 0.32 0.64 1.27 2.4
Maximum Torque
(N•m) 0.48 0.93 1.9 3.8 6.9
Rated Current
(A) 0.7 1.2 1.5 2.75 4.5
Maximum Current
(A) 1.75 3.6 4.5 8.3 13.5
Rotor Inertia
Kg•m
2
0.0232×10
-4
*0.0298×10
-4
(*With Brake)
0.0428×10
-4
*0.0494×10
-4
(*With Brake)
0.165×10
-4
*0.22×10
-4
(*With Brake)
0.272×10
-4
*0.326×10
-4
(*With Brake)
0.89×10
-4
*0.97×10
-4
(*With Brake)
Insulation Class Class B
Protection Class IP65(except shaft through hole and cable end connetor)
Oil Seal With Oil seal
AC
Servo
Drive
Drive Model Numbers
Pulse&Direction
Type
USB Mini
Basic Type
M2DV-1D82S M2DV-1D82S M2DV-1D82S M2DV-3D02S M2DV-4D52S
Q Type
M2DV-1D82Q M2DV-1D82Q M2DV-1D82Q M2DV-3D02Q M2DV-4D52Q
Fieldbus Type
RS-485
SCL
M2DV-1D82R M2DV-1D82R M2DV-1D82R M2DV-3D02R M2DV-4D52R
Modbus RTU
CAN CANopen
M2DV-1D82C M2DV-1D82C M2DV-1D82C M2DV-3D02C M2DV-4D52C
Ethernet
Ethernet/IP
M2DV-1D82IP M2DV-1D82IP M2DV-1D82IP M2DV-3D02IP M2DV-4D52IP
eSCL
M2DV-1D82E M2DV-1D82E M2DV-1D82E M2DV-3D02E M2DV-4D52E
