7.2.2.3 Parameter P-43 (SZ) Setting
Parameter P-43 (SZ)
’
s higher 8 digit and lower 8 digit set the definition for input filter frequency and pulse
type, the setting value are as shown in table below:
Filter
Frequency
pulse type
CW/CCW
condition
P-43 (SZ)
setting value
Filter
Frequency
pulse type
CW/CCW
condition
P-43 (SZ)
setting value
100K
Step &
Direction
X2 on 25344
500K
Step &
Direction
X2 on 4864
X2 Off 25348 X2 Off 4868
CW/CCW
Pulse On X1 25345
CW/CCW
Pulse On X1 4865
Pulse On X2 25349 Pulse On X2 4869
A/B
Quadrature
X1 Lead X2 25346
A/B
Quadrature
X1 Lead X2 4866
X2 Lead X1 25350 X2 Lead X1 4870
150K
Step &
Direction
X2 on 16640
750K
Step &
Direction
X2 on 3072
X2 Off 16644 X2 Off 3076
CW/CCW
Pulse On X1 16641
CW/CCW
Pulse On X1 3073
Pulse On X2 16645 Pulse On X2 3077
A/B
Quadrature
X1 Lead X2 16642
A/B
Quadrature
X1 Lead X2 3074
X2 Lead X1 16646 X2 Lead X1 3078
200
Step &
Direction
X2 on 12544
1M
Step &
Direction
X2 on 2304
X2 Off 12548 X2 Off 2308
CW/CCW
Pulse On X1 12545
CW/CCW
Pulse On X1 2305
Pulse On X2 12549 Pulse On X2 2309
A/B
Quadrature
X1 Lead X2 12546
A/B
Quadrature
X1 Lead X2 2306
X2 Lead X1 12550 X2 Lead X1 2310
250K
Step &
Direction
X2 on 9984
1.2M
Step &
Direction
X2 on 1792
X2 Off 9988 X2 Off 1796
CW/CCW
Pulse On X1 9985
CW/CCW
Pulse On X1 1793
Pulse On X2 9989 Pulse On X2 1797
A/B
Quadrature
X1 Lead X2 9986
A/B
Quadrature
X1 Lead X2 1794
X2 Lead X1 9990 X2 Lead X1 1798
300K
Step &
Direction
X2 on 8192
1.5M
Step &
Direction
X2 on 1280
X2 Off 8196 X2 Off 1284
CW/CCW
Pulse On X1 8193
CW/CCW
Pulse On X1 1281
Pulse On X2 8197 Pulse On X2 1285
A/B
Quadrature
X1 Lead X2 8194
A/B
Quadrature
X1 Lead X2 1282
X2 Lead X1 8198 X2 Lead X1 1286
400K
Step &
Direction
X2 on 6144
2.0M
Step &
Direction
X2 on 1024
X2 Off 6148 X2 Off 1028
CW/CCW
Pulse On X1 6145
CW/CCW
Pulse On X1 1025
Pulse On X2 6149 Pulse On X2 1029
A/B
Quadrature
X1 Lead X2 6146
A/B
Quadrature
X1 Lead X2 1026
X2 Lead X1 6150 1030
