 INSTRUCTION
 IQ80‐02E
Issuedof:JohanSPage 1/2
Approvedof: Edition
Date2012‐10‐20 SwingdoorslowspeedPCB Replace.

m:\kvalitet\kvalitetssystemet\working area\iqe_mc2000\klara\iq80-02e_swingdoor_slowspeed.docx
TheoptionslowspeedPCBtakesdownthespeedintheendofopeningandclosingcycle.

Function:
Thereisonepositionmagnetfittedonthelamelladiscunderthebigcogwheel.Themagnetshall
activatethesensorontheboardwhenthedooropenerarmispointingstraightoutfromthe
shortsideofthehousing.Onwhichsidethearmshallbefitteddependsondoorhanging.
Example:Righthingeddoor=thearmispointinginthesamedirectionasthePCBisfitted.

Therearedifferentpotentiometerswhereyoucanadjustthetimedelaybefore
thelowspeed
shallstartinopenandinclosingdirection.Youcanalsoadjusttheslowspeed.

Howeverthedoormachineisnowdeliveredwiththearmnotfittedandthemagnetpositionis
justatthesensor.Justfollowtheinstructiononthenextpage.












Instructionmechanic:
1. MakesurethereisnopowertotheswingdoorsTurnofthemainswitch!
2. Whenit’stimetofittheswingdoormachine,fitthemachineonthedoorframewithoutthe
armandtrackfittedwhentheswingdoorisinclosedposition.
3. Whenthe
machineisfitted,installthearmonthemachine.Thearmshallpointinthe
directionoppositethehingeside.
4. Treadthetrackonthearmwheel,openthedooralittleandfitthetrackonthedoor.(if
necessary,moveorinstallthemechanicalstoptocorrectsideasusual)


