INSTRUCTION
IQ80‐02E
Issuedof:JohanS Page 2/2
Approvedof: Edition
Date2012‐10‐20 SwingdoorslowspeedPCB Replace.
m:\kvalitet\kvalitetssystemet\working area\iqe_mc2000\klara\iq80-02e_swingdoor_slowspeed.docx
Instructionelectrical:
1. ConnectthecablefromthedoorframetothePCBterminalS1orS2(50‐50thatthesupply
polarizationisrightfromthebeginning)
2. Closealldoorsmanually.
3. NowturnthepowerONandgivethecontrollersignaltoopenthedoorontheactualfloor
youwanttoadjust.Nowwatchwhatlightisilluminated,redorgreen.(Donotcareabout
whatdirectionthedoorismovingatinthisstep)
4. Whenthecontrolpanelintendtoopentheswingdoor,thegreenLEDshallalwaysbeactive!
Iftheredisactive!SwoptheS1/S2supplyplug.(Donotcareaboutwhatdirectionthedoor
ismovingatinthisstepeither
)
5. Nowwhenthesupplypolarizationisright,youhavetocheckthemotorpolarization.Ifthe
doorisclosingwhenthegreenLEDisilluminatedyouonlyhavetomovethemotortermin
al
connectedtoM1orM2onestep.
Instructionadjustingtheslowspeedtimedelaysandslowspeed:
1. Turnuptheopeningtimeonthemaincontrollersothedoorforsureopens90degrees.
2. Adjustthetimedelaybeforetheslowspeedisactivatedintheopeningdirectiononthe
potentiometerP2(AbovegreenLED)Clockwiseincreasethetimedelay.Theslowspeedshall
startjustalittlebeforefullyopendoor.
3. YoucanifnecessaryadjusttheslowspeedonpotentiometerP2(AboveblueLED)
4. Adjustthetimedelaybeforetheslowspeedisactivatedintheclosingdirectiononthe
potentiometerP3(AboveredLED)Clockwiseincreasethetimedelay.Theslowspeedshall
startjustalittlebeforethedoorhitsthedoorframe.
5. Whenyouarehappywiththespeedsadjusttheopeningtimeagainonthemaincontroller.
Thetimeshallnotbemuchlongerthanittakestoopenthedoorfully.
MeaningofthePotentiometers:
RedLED=Doorisclosing
GreenLED=Doorisopening
BlueLEDflashing=Sensorhasbeenactivated.Timercountdownbeforeslowspeedhasstarted
BlueLED=Slowspeed
YellowLED=Sensoractivatedbythemagnet.Normallywhenthedoorarmisinparallelposition
comparedtothedoorframe.
P1=Lowspeedadjustment
P2=Delaybeforeslowspeedafterthemagnetha
spassedthesensorinopendirection.4‐10sec
P3=Delaybeforeslowspeedafterthemagnetha
spassedthesensorinclosingdirection.0‐1.5
sec
