Device Configuration 5 - 47
Figure 5-27 Access Point Radio - Advanced Settings tab
23. Refer to the Aggregate MAC Protocol Data Unit (A-MPDU) field to define how MAC service frames are aggregated by
the access point radio.
24. Use the Aggregate MAC Service Data Unit (A-MSDU) drop-down menu to set the supported A-MSDU mode.
Available modes include Receive Only and Transmit and Receive. Transmit and Receive is the default value. Using Transmit
and Receive, frames up to 4 KB can be sent and received. The buffer limit is not configurable.
25. Set the following Aeroscout Properties for the selected access point radio:
26. Set the following Ekahau Properties for the selected access point radio:
A-MPDU Modes Use the drop-down menu to define the A-MPDU mode supported. Options include
Transmit Only, Receive Only, Transmit and Receive and None. The default value is
Transmit and Receive. Using the default value, long frames can be both sent and received
(up to 64 KB). When enabled, define either a transmit or receive limit (or both).
Minimum Gap Between
Frames
Use the drop-down menu to define the minimum gap between A-MPDU frames (in
microseconds). The default value is 4 microseconds.
Received Frame Size
Limit
If a support mode is enable allowing A-MPDU frames to be received, define an advertised
maximum limit for received A-MPDU aggregated frames. Options include 8191, 16383,
32767 or 65535 bytes. The default value is 65535 bytes.
Transmit Frame Size
Limit
Use the spinner control to set limit on transmitted A-MPDU aggregated frames. The
available range is from 2000 - 65,535 bytes). The default value is 65535 bytes.
Forward Use the Forward option to forward Aeroscout packets to the server.
MAC to be forwarded Use the text area to provide a MAC address that identifies that the packet is received
from Aeroscout tags.
Forwarding Host Use the Forward Host text area to provide the IP address of the Ekahau Engine.
