Device Configuration 5 - 155
Figure 5-98 Mesh Connex Auto Channel Selection screen
9. By default, the Dynamic Root Selection screen displays.
This screen provides configuration for the 2.4 GHz and 5.0/4.9 GHz frequencies. Refer to the following for more information
on the Auto Channel Selection Dynamic Root Selection screen. These descriptions are common for configuring the 2.4 GHZ
and 5.0/4.9 GHz frequencies
Channel Width Configure the channel width that mesh point automatic channel scan should assign to the
selected radio. The available options are:
• Automatic – Indicates the channel width is calculated automatically. This is the
default value.
• 20 MHz – Indicates the width between two adjacent channels is 20 MHz.
• 40 MHz – Indicates the width between two adjacent channels is 40 MHz.
Priority Meshpoint Configure the mesh point monitored for automatic channel scan. This is the mesh point
given priority over other available mesh points. When configured, a mesh is created with
this mesh point. When not configured, a mesh point is automatically selected.
