Device Configuration 5 - 169
Figure 5-106 Advanced Profile Configuration - MINT Protocol screen - Add/edit VLAN field
14. Set the following parameters to add or modify MINT VLAN configuration:
15. Select OK to save the updates to the MINT Protocol configuration. Select Reset to revert to the last saved configuration.
VLAN If adding a new VLAN, define a VLAN ID from 1 - 4,094 used by peers for
interoperation when supporting the MINT protocol.
Routing Level If adding a new VLAN, use the spinner control to define a routing level of either 1 or 2.
Link Cost Use the spinner control to define a link cost from 1 - 10,000. The default value is 100.
Hello Packet Interval Set an interval in either Seconds (1 - 120) or Minutes (1 - 2) for the transmission of
hello packets. The default interval is 4 seconds.
Adjacency Hold Time Set a hold time interval in either Seconds (2 - 600) or Minutes (1 - 10) for the
transmission of hello packets. The default interval is 13 seconds.
