Device Configuration 5 - 261
Figure 5-161 Device Overrides - Network - OSPF Interface Settings screen
22. Review existing Interface Settings using:
23. Select the Add button to define a new set of virtual interface basic settings, or Edit to update the settings of an existing
virtual interface configuration.
Name Displays the name defined for the interface configuration.
Type Displays the type of interface.
Description Lists each interface’s 32 character maximum description.
Admin Status Displays whether Admin Status privileges have been enabled or disabled for the OSPF
route’s virtual interface connection.
VLAN Lists the VLAN IDs set for each listed OSPF route virtual interface.
IP Address Displays the IP addresses defined as virtual interfaces for dynamic OSPF routes. Zero
config and DHCP can be used to generate route addresses, or a primary and secondary
address can be manually provided.
