5 - 260 WiNG 5.5 Access Point System Reference Guide
Figure 5-160 Device Overrides - Network - OSPF Area Configuration screen
19. Set the OSPF Area configuration.
20. Select the OK button to save the changes to the area configuration. Select Reset to revert to the last saved configuration.
21. Select the Interface Settings tab.
Area ID Use the drop-down menu and specify either an IP address or Integer for the OSPF area.
Authentication Type Select either None, simple-password or message-digest as credential validation
scheme used with the OSPF dynamic route. The default setting is None.
Type Set the OSPF area type as either stub, totally-stub, nssa, totally-nssa or non-stub.
Default Cost Select this option to set the default summary cost advertised if creating a stub. Set a
value from 1 - 16, 777,215.
Translate Type Define how messages are translated. Options include translate-candidate, translate-
always and translate-never. The default setting is translate-candidate.
Range Specify a range of addresses for routes matching address/mask for OSPF
summarization.
