Device Configuration 5 - 273
3. Select a target device from the device browser in the lower, left-hand, side of the UI.
4. Select Network to expand its sub menu options.
5. Select Link Layer Discovery Protocol.
Figure 5-170 Link Layer Discovery Protocol (LLDP) screen
6. Set the following LLDP parameters for the profile configuration:
7. Select the OK button to save the changes and overrides to the LLDP configuration. Select Reset to revert to the last saved
configuration.
5.4.5.4.13Overriding a Miscellaneous Network Configuration
Overriding the Network Configuration
An access point profile can be configured to include a hostname in a DHCP lease for a requesting device and its profile. This
helps an administrator track the leased DHCP IP address by hostname for a device profile. When numerous DHCP leases are
assigned, an administrator can better track the leases when hostnames are used instead of devices.
Enable LLDP Select this option to enable LLDP on the access point. LLDP is enabled by default. When
enabled, an access point advertises its identity, capabilities and configuration information
to connected peers and learns the same from them.
Hold Time Use the spinner control to set the hold time (in seconds) for transmitted LLDP PDUs. Set a
value from 10 - 1,800. The default hold time is 180 seconds.
Timer Set the interval used to transmit LLDP PDUs. Define an interval from 5 - 900 seconds. The
default setting is 60 seconds.
Inventory Management
Discovery
Select this option to include LLPD-MED inventory management discovery TLV in LLDP
PDUs. This setting is enabled by default.
Extended Power via MDI
Discovery
Select this option to include LLPD-MED extended power via MDI discovery TLV in LLDP
PDUs. This setting is disabled by default.
