5 - 306 WiNG 5.5 Access Point System Reference Guide
Figure 5-197 Device Overrides - VRRP screen - VRRP tab
5. Review the following VRRP configuration data to assess if a new VRRP configuration is required or if an existing VRRP
configuration requires modification or removal:
6. Select the Version tab to define the VRRP version scheme used with the configuration.
Virtual Router ID Lists a numerical index (from 1 - 254) used to differentiate VRRP configurations. The index
is assigned when a VRRP configuration is initially defined. This ID identifies the virtual
router a packet is reporting status for.
Description Displays a description assigned to the VRRP configuration when it was either created or
modified. The description is implemented to provide additional differentiation beyond the
numerical virtual router ID.
Virtual IP Addresses Lists the virtual interface IP address used as the redundant gateway address for the
virtual route.
Interface Displays the interfaces selected on the access point to supply VRRP redundancy failover
support.
Priority Lists a numerical value (from 1 - 254) used for the virtual router master election process.
The higher the numerical value, the higher the priority in the election process.
