5 - 332 WiNG 5.5 Access Point System Reference Guide
15. Select MINT Protocol. The MINT Protocol screen displays the Settings tab by default.
Figure 5-213 Device Overrides - Advanced Profile Overrides MINT screen - Settings tab
16. Refer to the Area Identifier field to define or override the Level 1 and Level 2 Area IDs used by the profile’s MINT
configuration.
17. Define or override the following Priority Adjustment settings:
18. Select the Latency of Routing Recalculation option (within the Shortest Path First (SPF) field) to enable the spinner
control used for defining or overriding a latency period from 0 - 60 seconds. The default setting has the option disabled.
Max confirmed
Neighbors
Use the spinner to set the maximum number of learned neighbors stored at this device.
Minimum signal
strength for smart-rf
neighbors
Use the spinner to set the minimum signal strength of neighbor devices that are learnt
through Smart RF before being recognized as neighbors.
Level 1 Area ID Select this option to enable a spinner control for setting the Level 1 Area ID from 1 -
4,294,967,295. The default value is disabled.
Designated IS Priority
Adjustment
Use the spinner control to set a Designated IS Priority Adjustment setting from -255 -
+255. This is the value added to the base level DIS priority to influence the Designated
IS (DIS) election. A value of +1 or greater increases DISiness. The default setting is 0.
