7 - 26 WiNG 5.5 Access Point System Reference Guide
Figure 7-16 AAA TACACS Policy - New Authentication Server
9. Define the following settings to add or modify AAA TACACS authentication server configuration:
10. Click OK to close the Authentication Server dialog and save the changes. Click Reset to revert to the last saved
configuration. Click Exit to close the Authentication Server dialog.
11. Click the Accounting tab. The following screen displays:
NOTE: Only 2 AAA TACACS Authentication servers can be configured at a time.
Server Id Displays the numerical server index (1-2) for the authentication server when added to the
list available to the access point.
Host Specify the IP address or hostname of the AAA TACACS authentication server.
Port Define or edit the port on which the AAA TACACS server listens to traffic within the
access point managed network. The port range is 1 - 65,535. The default port is 49.
Secret Specify the secret (password) used for authentication on the selected AAA TACACS
server. By default the secret is displayed as asterisks.
When a secret is entered, it must be confirmed in the Reconfirm text box.
Request Attempts Displays the number of attempts a client can retransmit a missed frame to the AAA
TACACS server before it times out of the authentication session. The available range is
from 1 - 10. The default is 3.
Request Timeout Specify the time for the access point’s re-transmission of request packets. The default is
3 seconds. If this time is exceeded, the authentication session is terminated.
Retry Timeout Factor Specifies the interval, in seconds, between two successive re-transmission attempts.
Specify a value from 50 - 200 seconds. The default is 100 seconds.
