Statistics 13 - 37
10.Select the Device Brief Info tab from the top of the screen.
The Device Brief Info screen is divided into 2 fields, All Roots and Mesh Points and MeshPoint Details.
Figure 13-22 RF Domain - Mesh Point Device Brief Info screen
The All Roots and Mesh Points field displays the following:
Proxy Address Displays the MAC Address of the proxy used in the mesh point.
Age Displays the age of the proxy connection for each of the mesh points in the RF Domain.
Proxy Owner The owner’s (MPID) is used to distinguish the neighbor device.
Persistence Displays the persistence (duration) of the proxy connection for each of the mesh points in
the RF Domain.
VLAN The VLAN ID used as a virtual interface with this proxy. A value of 4095 indicates that
there is no VLAN ID.
MAC Displays the MAC Address of each configured mesh point in the RF Domain.
Mesh Point Name Displays the name of each configured mesh point in the RF Domain.
