13 - 38 WiNG 5.5 Access Point System Reference Guide
11.The MeshPoint Details field on the bottom portion of the screen displays tabs for General, Path, Root, Multicast Path,
Neighbors, Security and Proxy. Refer to the following:
The General tab displays the following:
Hostname Displays the administrator assigned hostname for each configured mesh point in the RF
Domain.
Configured as Root A root mesh point is defined as a mesh point connected to the WAN, providing a wired
backhaul to the network (Yes/No).
Is Root Indicates whether the current mesh point is a root mesh point (Yes/No).
Destination Addr The destination is the endpoint of mesh path. It may be a MAC address or a mesh point ID.
Root Hops The number of devices between the selected mesh point and the destination device.
IFID Count Displays the number of Interface IDs (IFIDs) associated with all the configured mesh
points in the RF Domain.
Mesh Point Name Displays the name of each configured mesh point in the RF Domain.
MAC Displays the MAC Address of each configured mesh point in the RF Domain.
Hostname Displays the hostname for each configured mesh point in the RF Domain.
Configured as Root A root mesh point is defined as a mesh point that is connected to the WAN and provides
a wired backhaul to the network. (Yes/No)
Is Root A root mesh point is defined as a mesh point that is connected to the WAN and provides
a wired backhaul to the network. (Yes/No)
Destination Addr The destination is the endpoint of mesh path. It may be a MAC address or a mesh point ID.
Interface ID Uniquely identifies an interface associated with the ID. Each mesh point on a device can
be associated with one or more interfaces.
Root Interface Lists the radio interface on which the mesh point operates.
Next Hop IFID Identifies the ID of the interface on which the next hop for the mesh network can be found.
Next Hops Use Time Lists the time when the next hop in the mesh network topology was last utilized.
Root Hops Number of hops to a root and should not exceed 4 in general practice. If using the same
interface to both transmit and receive, then you will get approximately half the
performance every additional hop out.
Root MP ID Lists the interface ID of the interface on which the next hop for the mesh network can be
found.
Root Bound time Displays the duration this mesh point has been connected to the mesh root.
IFID Count Displays the number of Interface IDs (IFIDs) associated with all the configured mesh
points in the RF Domain.
