Motorola XPR 5550 User Manual

78 156.925 161.525
79 156.975 161.575
80 157.025 161.625
* 157.075 161.675
* 157.125 161.725
* 157.175 161.775
84 157.225 161.825
85 157.275 161.875
86 157.325 161.925
87 157.375 161.975
88 157.425 162.025
Note:
* Simplex channels 3, 21, 23, 61, 64, 81, 82,
and 83 cannot be lawfully used by the
general public in US waters.
** Low power (1 W) only.
*** Guard band.
Note:
A – in the Receive column indicates that the
channel is transmit only.
Declaration of Compliance for the Use of
Distress and Safety Frequencies
The radio equipment does not employ a modulation
other than the internationally adopted modulation for
maritime use when it operates on the distress and
safety frequencies specified in RSS-182 Section 7.3.
Technical Parameters for Interfacing External
Data Sources
RS232 USB SB9600
Input Volt-
age (Volts
Peak-to-
peak)
18V 3.6V 5V
Max Data
Rate
28 kb/s 12 Mb/s 9.6 kb/s
Impedance 5000 ohm 90 ohm 120 ohm
Maritime Radio Use in the VHF Frequency Range
402
English

Motorola XPR 5550 Specifications

General

GPS	Yes
Bluetooth	Yes
IP Rating	IP54
Operating Temperature	-30°C to +60°C
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Weight	1.8 kg (4.0 lbs)
Display	Yes, Alphanumeric
Digital Protocol	DMR
Encryption	AES/DES Encryption
Channel Capacity	1000 channels
