7 Functions and settings
112 TAPCON® 230 basic 2117246/02 EN © Maschinenfabrik Reinhausen 2012
7.4.1 Transformer data
The transformation ratios and measuring set-up for the voltage and current
transformers used can be set in the relevant displays.
The relevant settings are described in the following sections.
7.4.1.1 Setting the primary transformer voltage
The device displays the secondary transformer voltage (in V) as standard. In
order to display the primary transformer voltage (in kV), you have to set "kV"
as the unit for the voltage display (page 120).
The setting variants are shown in the table below.
Primary voltage Secondary voltage Setting Display
No parameterization 100 V V 100 V
110 kV 100 V kV 110 kV
Table 30 Example of display variants
