MR TAPCON 230 basic User Manual

7 Functions and settings
146 TAPCON® 230 basic 2117246/02 EN © Maschinenfabrik Reinhausen 2012
Key
LED no. LED
LED 1 AUTO
LED 2 MANUAL
LED 3 LOWER
LED 4 RAISE
LED 5 >I
+
LED 6 <V
+
LED 7 >V
+
LED 8 Parallel operation
+
LED 9 NORMSET
All LEDs All LEDs
Table 45 Selecting the LEDs for tests
7.5.5 Displaying MIO inputs
The statuses of the optocoupler inputs are shown in this display. As soon as a
continuous signal is present at the input, status "1" is displayed. "0" indicates
no signal at the input.
To display the "MIO inputs", proceed as follows:
► > Info > 4x .
<04> MIO inputs.
