3 Product description
20 TAPCON® 230 basic 2117246/02 EN © Maschinenfabrik Reinhausen 2012
3.1 Performance features
The voltage regulator is responsible for controlling tapped transformers.
Apart from control tasks, the voltage regulator provides additional functions
such as:
 Integrated protective functions:
 Undervoltage and overcurrent blocking
 Overvoltage detection with high-speed return
 Line drop compensation
 Compensation for voltage fluctuations in the meshed grid (Z compensa-
tion)
 Digital inputs and outputs can be individually programmed on-site by the
user
 Additional indicators using LEDs outside the display for freely selectable
functions
 Display of all measured values such as voltage, current, active power, ap-
parent power or reactive power, power factor (cos φ)
 Plug terminals make it easier to connect the cables
 Selection of 3 different desired values
3.1.1 Operating modes
The device can be operated in the following operating modes:
AUTO/MANUAL
In auto mode (AUTO), the voltage is automatically controlled in accordance
with the set parameters. The settings cannot be changed in auto mode.
In manual mode (MANUAL), no automatic control occurs. The motor-drive unit
can be controlled via the device's operating panel. The settings can be
changed.
LOCAL/REMOTE
In remote mode (REMOTE), commands from an external control interface are
executed. In this case, manual operation of the
, , and
keys is disabled.
