5.4.3 Connecting the cables to the system periphery
Connect the lines to be wired to the device to the system periphery as shown
in the connection diagrams supplied.
WARNING
Electric shock
Connection mistakes may endanger life
► Earth the voltage regulator using the grounding screw on the housing.
► Pay attention to the phase difference of the secondary terminals for the
current and voltage transformers.
► Connect the output relays correctly to the motor-drive unit.
NOTICE
Damage to device and system periphery
An incorrectly connected device can lead to damages in the device and
system periphery.
► Prior to commissioning, be sure to check the entire configuration and the
actual and operating voltage.
To obtain a better overview when connecting cables, only use as many leads
as necessary.
Use only the specified cables for wiring. You will find a cable recommendation
in the corresponding section (see "Cable recommendation" on page 48).
When wiring, proceed as described in the Wiring (see "Wiring the device"
on page 55) section.
