MR TAPCON 230 basic User Manual

7 Functions and settings
140 TAPCON® 230 basic 2117246/02 EN © Maschinenfabrik Reinhausen 2012
7.4.4 LED selection
You can use the settings in this sub-menu to assign functions to the 4 free
LEDs.
You can use labeling strips to label them.
7.4.4.1 Functions available
An overview of all the functions which you can assign to the LEDs is provided
in the table below:
Function Description
1 Off LED deactivated
2 GPI 1 There is a signal at the GPI 1 input.
3 GPI 2 There is a signal at the GPI 2 input.
4 GPI 3 There is a signal at the GPI 3 input.
5 GPI 4 There is a signal at the GPI 4 input.
6 GPI 5 There is a signal at the GPI 5 input.
7 GPI 6 There is a signal at the GPI 6 input.
8 GPO 1 The relay on the GPO 1 output has activated.
9 GPO 2 The relay on the GPO 2 output has activated.
10 Undercurrent Undercurrent detected.
11 Trip MPS Motor protective switch tripped.
12 Blocking Blocking was triggered.
13 Bandwidth < Value has fallen below bandwidth.
14 Bandwidth > Value has exceeded bandwidth.
15 Desired value 1 Desired value 1 active.
16 Desired value 2 Desired value 2 active.
17 Desired value 3 Desired value 3 active.
18
Function
monitoring
"Function Monitoring" message active.
19 Remote Remote mode active.
20 Local Local mode active.
21 Auto Auto mode active.
22 Manual Manual mode active.
Table 43 Possible functions for LEDs
