MR TAPCON 230 basic User Manual

7 Functions and settings
150 TAPCON® 230 basic 2117246/02 EN © Maschinenfabrik Reinhausen 2012
7.6 Summary of setting ranges
Parameter
name
Setting range Step size Factory setting
Desired value 1/2/3
49 V...140 V
0 kV... 9999 kV
0 kV...999.9 kV
0 kV...99.99 kV
0.1 V
1 kV
0.1 kV
0.01 kV
100 V
1 kV
1 kV
1 kV
Bandwidth
0.5 %...9% 0.01 % 2 %
Delay time T1
0 s...600 s 1 s 40 s
Delay time T2
1 s...10 s 0.1 s 10 s
V< Undervoltage (%)
60 %...100 %
of desired value
1 % 90 %
V< delay (signaling de-
lay time)
0 s...20 s 0.1 s 10 s
V> Overvoltage (%)
100 %...140 %
of desired value
1 % 110 %
I> Overcurrent
50 %...210 % 1 % 110 %
I< Undercurrent
0 %...210 % 1 % 0 %
Line drop compensa-
tion Vr
(ohmic voltage drop)
-25 V...25 V 0.1 V 0 V
Line drop compensa-
tion Vx
(inductive voltage drop)
-25 V...25 V 0.1 V 0 V
Z compensation
0 %...15 %
of desired value
0.1 % 0 %
Z compensation limit
value
0 %...15 %
of desired value
0.1 % 0 %
Primary transformer
voltage
0 kV... 9999 kV
0 kV...999.9 kV
0 kV...99.99 kV
1 kV
0.1 kV
0.01 kV
0 kV
0 kV
0 kV
Secondary transformer
voltage
57 V...123 V 0.1 V 100 V
Primary transformer
current
0 A – 9999 A 1 A 0 A
Raise/lower switching
pulse time
0 s...10 s 0.1 s 1.5 s
Regulator ID
0...9999 1 0
Operation counter
0...99999999 1 0
Function monitoring de-
lay time
0...120 minutes 1 minute 15 minutes
