MR TAPCON 230 basic User Manual

7 Functions and settings
78 TAPCON® 230 basic 2117246/02 EN © Maschinenfabrik Reinhausen 2012
7.2.3 Setting the secondary voltage
The secondary voltage is displayed and entered in V.
Setting range Step size Factory setting
57 V...123 V 0.1 V 100 V
Table 11 Setting range for secondary voltage in V
To set the secondary voltage, proceed as follows:
1.
> Normset > 3x .
<03> Secondary voltage.
2. If necessary Press
to highlight the de-
cimal place.
The decimal place is defined and the value
can be changed.
3. Press
to highlight a digit.
The digit position you want is highlighted
and the value can be changed.
4. Press
to increase the value or to
reduce it.
5. Press
.
The secondary voltage is set.
