7 Functions and settings
© Maschinenfabrik Reinhausen 2012 2117246/02 EN TAPCON® 230 basic 73
7.1.2 Deactivating key lock
To deactivate the key lock, proceed as follows:
► Press
and at the same time.
The key lock is deactivated. Parameters can be
entered.
7.2 NORMset
As an alternative to parameterizing the voltage regulator manually, the
NORMset mode enables easy commissioning of the voltage regulator with a
limited set of parameters. When this mode is selected, the factory settings re-
quired for voltage regulation are adopted.
When commissioning the voltage regulator in NORMset mode, the following
parameters must be set:
 Desired value 1
 Primary voltage
 Secondary voltage
When these 3 parameters have been set, the voltage regulator is ready to op-
erate.
Once NORMset has been activated, no additional settings can be undertaken
for line drop compensation.
The desired value is compared with the measured voltage present on the vol-
tage regulator depending on the unit defined, i.e. V (secondary voltage of vol-
tage transformer) or kV (primary voltage of voltage transformer). If additional
information on current and phase angle are required, connect the current
transformer and adjust the current connection data (see "Setting the cur-
rent transformer connection" on page 116).
