MR TAPCON 230 basic User Manual

3 Product description
© Maschinenfabrik Reinhausen 2012 2117246/02 EN TAPCON® 230 basic 27
3.4.2 Description of the display
The device has a monochrome display with graphics capabilities.
Figure 6 Main screen
1 Status line
2 Measured voltage (V
actual
)
3 Reference voltage (V
reference
)
4
Other measured values (use or to switch between
them)
5 Bandwidth (upper and lower limit)
6 Time bar for delay time T1
7 Highlighting for reference voltage
8 Highlighting for measured voltage (V
actual
)
9 Remaining delay time T1
