9 Technical Data
© Maschinenfabrik Reinhausen 2012 2117246/02 EN TAPCON® 230 basic 161
9 Technical Data
9.1 Indicator elements
Display
LCD, monochrome, graphics-capable
128 x 128 pixels
LEDs 15 LEDs for operation display and messages of
which 4 LEDs are freely programmable (2x yel-
low, 1x yellow/green, 1x yellow/red)
Table 54 Indicator elements
9.2 Electrical data
Power supply
110 (-20%)...350 V DC
88...265 V AC
Power consumption TAPCON® 230 pro: 12.5 VA
TAPCON® 230 expert: 15 VA
Table 55 Electrical data
9.3 Dimensions and weight
Housing (W x H x D)
198 x 310 x 95.5 mm
Door (W x H)
242 x 343 mm
Weight
6.0 kg
Table 56 Dimensions and weight
