7 Functions and settings
© Maschinenfabrik Reinhausen 2012 2117246/02 EN TAPCON® 230 basic 79
7.3 Control parameters
This section describes all the functions, parameters and recommended setting
ranges for voltage regulation. You will always find the description for a para-
meter or parameter screen with the description for the corresponding subme-
nu.
7.3.1 Voltage regulation
This submenu contains all the parameters required for the control function.
 Desired value 1, 2 and 3
 Bandwidth
 Delay time T1
 Control response T1
 Delay time T2
7.3.2 Desired voltage values
One important fixed value is the desired voltage level V
Des
. You can enter the
desired value via the user interface in both the NORMset and the correspond-
ing parameter screen of the voltage regulation sub-menu.
During operation, you can change the level of a desired value and change be-
tween different desired values. You use the GPI5 and GPI6 binary inputs to
define whether desired value 1, 2 or 3 is active.
The default desired value is desired value 1.Desired values 2 or 3 are acti-
vated if there is a continuous signal at the pre-assigned GPIs 5 or 6 (factory
preset). If there is a signal at both inputs at the same time, desired value 2 is
active.
The following sections describe how to set the desired values.
