MR TAPCON 230 basic User Manual

3 Product description
30 TAPCON® 230 basic 2117246/02 EN © Maschinenfabrik Reinhausen 2012
3.4.4 Description of LEDs
LEDs above the display indicate various operating statuses or events.
Figure 7 Description of LEDs
1 Green Operating display
2 Red Overcurrent blocking
3 Red Undervoltage blocking
4 Red Overvoltage blocking
5 Green Parallel operation On
6 Green NORMset On
7 Yellow Configurable (LED1)
8 Yellow Configurable (LED2)
9 Yellow/green Configurable (LED3)
10 Yellow/red Configurable (LED4)
