MR TAPCON 230 basic User Manual

5 Mounting
48 TAPCON® 230 basic 2117246/02 EN © Maschinenfabrik Reinhausen 2012
5.4 Connection
5.4.1 Cable recommendation
Please note the following recommendation from Maschinenfabrik Reinhausen
when wiring the device.
Cable Terminal Cable type Wire cross-
section
Max. perm.
torque
Signal inputs X4:13 to 24 shielded 1.5 mm² 0.6 Nm
RS232 SUB-D - shielded 0.25 mm² -
Relay outputs* X3:1 to 12 unshielded 1.5 mm² 0.6 Nm
Relay outputs* optional X4:1 to 12 unshielded 1.5 mm² 0.6 Nm
Current measurement X1: 5/6/9 unshielded 4 mm² 1.5 Nm
Voltage measurement X2: 1/2 shielded 1.5 mm² 0.6 Nm
Power supply X2: 3/4 unshielded 1.5 mm² 0.6 Nm
Cable clips X1 to X4 are on the MIO card (see "Wiring the device" on page 55) of the de-
vice.
Table 6 Recommendation for connection cable
NOTE
Output relay malfunction
Excessive electrical power can prevent the relay contacts from break-
ing the contact current.
► The effect of the cable capacitance of long control lines in control cir-
cuits operated with alternating current on the function of the relay con-
tacts must be taken into account.
5.4.2 Electromagnetic compatibility
The product was developed in compliance with the relevant EMC standards.
To ensure compliance with the EMC standards, please note the following
points.
