5 Mounting

5.4.2.1 Wiring requirement of installation site

Note the following when selecting the installation site:

 The system's overvoltage protection must be effective.

 The system's ground connection must comply with all technical regula-

tions.

 Separate system parts must be joined by a potential equalization.

 The voltage regulator and its wiring must be at least 10 m away from cir-

cuit-breakers, load disconnectors and busbars.

5.4.2.2 Wiring requirement of operating site

Note the following when wiring the operating site:

 The connection cables must be laid in metallic cable ducts with a ground

connection.

 Do not route lines which cause interference (e.g. power lines) and lines

susceptible to interference (e.g. signal lines) in the same cable duct.

 Maintain a gap of at least 10 cm between lines causing interference and

those susceptible to interference.

 Reserve lines must be grounded at both ends.

 The voltage regulator must never be connected using four-pin collective

cables.
