5 Mounting
© Maschinenfabrik Reinhausen 2012 2117246/02 EN TAPCON® 230 basic 39
Figure 10 Rear view
1 Hexagonal recess head screw of mounting bracket
2 Mounting bracket
3 Hexagonal recess head screw of M connecting plate
4 M connecting plate
