3 Product description
Maschinenfabrik Reinhausen 201426 3550953/00 ENTAPCON® 230 pro
PIO card
Figure 13: PIO card
1 Signal inputs and auxiliary
voltage generation (terminal
X6)
4 Relay outputs (terminal X5)
2 Analog input (terminal X7) 5 Relay outputs (terminal X5)
3 Digital tap position inputs (ter-
minal X6)
3.5.5.2
