7 Control system protocol
Maschinenfabrik Reinhausen 2014 1272374092/04 EN TAPCON® 260
Control system protocol
Protocol specification
The device provides an extract of commands and messages from the inter-
face protocol IEC 61850 for communication.
You can find the device-specific data points and presettings in the device's
ICD file. You can request the following documents for the device or down-
load from the device:
▪ MICS (Model Implementation Conformance Statement)
▪ PICS (Protocol Implementation Conformance Statement)
▪ PIXIT (Protocol Implementation eXtra Information for Testing)
▪ TICS (Technical Issues Conformance Statement)
Please note possible restrictions and comments regarding device specific
data points and default settings listed in the documents above.
Downloading ICD file
You can download the ICD file via FTP from the device. You have to estab-
lish an ethernet connection between the device and your PC.
For a smooth download with Windows Vista/7/8 operating systems, use
Windows Explorer.
Proceed as follows to download the ICD file:
1. Enter ftp://gast@<IP adress> in your browser (in the example in
the diagram below, the IP adress is 192.168.0.1) and select the directo-
ry home/gast.
7
7.1
Device-specific data points
7.1.1
