7 Control system protocol
Maschinenfabrik Reinhausen 2014 1352374092/04 EN TAPCON® 260
GGIO3 - Generic process I/O
Attribute
name
Attribute
type
Explanation M/O/E Remarks
GGIO3 - GPIO UC2 - -
Common logical node information
Mod ENC Mode O status-only
Beh INS Behavior M -
Health INS Health O 1 = OK; 3 = no
internal com-
munication
NamPlt LPL Name plate O -
Controls
- - - - -
Measured values
- - - - -
Status information
Ind1 SPS UC2 X1:11 O -
Ind2 SPS UC2 X1:12 O -
Ind3 SPS UC2 X1:14 O -
Ind4 SPS UC2 X1:15 O -
Ind5 SPS UC2 X1:16 O -
Ind6 SPS UC2 X1:17 O -
Ind7 SPS UC2 X1:30 O -
Ind8 SPS UC2 X1:31 O -
Ind9 SPS UC2 X1:32 O -
Ind10 SPS UC2 X1:33 O -
Settings
- - - - -
Table 41: GGIO class (GGIO3)
GGIO4 - Generic process I/O
Attribute
name
Attribute type Explanation M/O/E Remarks
GGIO4 - GPIO UC3 - -
Common logical node information
Mod ENC Mode O status-only
Beh INS Behavior M -
Health INS Health O 1 = OK; 3 = no inter-
nal communication
NamPlt LPL Name plate O -
Controls
- - - - -
7.2.9
7.2.10
