12 Overview of parameters
Maschinenfabrik Reinhausen 2014148 2374092/04 ENTAPCON® 260
Overview of parameters
This section contains an overview of the relevant menus and parameters.
Parameter Setting range Factory setting Current setting
Parameter > Normset
Normset activation On/Off Off
Primary voltage 0...9,999 kV 0 kV
Secondary voltage 57...125 V 100 V
Desired value 1 49...140 V 100 V
Parameter > Control parameter
Bandwidth 0.5...9 % 1.00 %
Desired value 1 49...140 V 100.0 V
Desired value 2 49...140 V 100.0 V
Desired value 3 49...140 V 100.0 V
Desired value at 0 active
power
49...140 V 100.0 V
T1 control response T1 linear/T1 integral T1 linear
T1 delay time 0...600 s 40 s
T2 activation T2 on/T2 off T2 off
T2 delay time 1...60 s 10.0 s
Parameter > Limit values
Fct. Monitoring On/Off Off
Absolute limit values On/Off Off
I> Overcurrent 50...210 % 110 %
Tap max. -128...128 128
Tap min. -128...128 -128
U< blocking On/Off On
U< Undervoltage (%) 60...100 % 90 %
U< Undervoltage (V) 34...160 V 90.0 V
U< Delay 0...20 s 10.0 s
U< also under 30 V On/Off Off
U> Overvoltage (%) 100...140 % 110.0 %
U> Overvoltage (V) 34...160 V 110.0 V
Parameter > Compensation
Ur line drop comp. -25...25 V 0.0 V
Ux line drop comp. -25...25 V 0.0 V
Z comp. limit value 0...15 % 0.0 %
Z compensation 0...15 % 0.0 %
Parameter > Cross-monitoring
Error message 0...10 s 10 s
U prim. regulator 2 0...9,999 kV 0 kV
U sec. regulator 2 57...125 V 100.0 V
12
