7 Control system protocol
Maschinenfabrik Reinhausen 2014134 2374092/04 ENTAPCON® 260
Attribute
name
Attribute
type
Explanation M/O/E Remarks
Ind4 SPS IO X1:17 O -
Ind5 SPS IO X1:14 O -
Ind6 SPS IO X1:13 O -
Ind7 SPS IO X1:11 O -
Ind8 SPS IO X1:12 O -
Ind9 SPS IO X1:29 O -
Ind10 SPS IO X1:28 O -
Settings
- - - - -
Table 39: GGIO class (GGIO1)
GGIO2 - Generic process I/O
Attribute
name
Attribute
type
Explanation M/O/E Remarks
GGIO2 - GPIO UC1 - -
Common logical node information
Mod ENC Mode O status-only
Beh INS Behavior M -
Health INS Health O 1: OK; 3: no in-
ternal communi-
cation
NamPlt LPL Name plate O -
Controls
- - - - -
Measured values
- - - - -
Status information
Ind1 SPS UC1 X1:11 O -
Ind2 SPS UC1 X1:12 O -
Ind3 SPS UC1 X1:14 O -
Ind4 SPS UC1 X1:15 O -
Ind5 SPS UC1 X1:16 O -
Ind6 SPS UC1 X1:17 O -
Ind7 SPS UC1 X1:30 O -
Ind8 SPS UC1 X1:31 O -
Ind9 SPS UC1 X1:32 O -
Ind10 SPS UC1 X1:33 O -
Settings
- - - - -
Table 40: GGIO class (GGIO2)
7.2.8
