7 Control system protocol
Maschinenfabrik Reinhausen 2014136 2374092/04 ENTAPCON® 260
Attribute
name
Attribute type Explanation M/O/E Remarks
Measured values
- - - - -
Status information
Ind1 SPS UC3 X1:11 O -
Ind2 SPS UC3 X1:12 O -
Ind3 SPS UC3 X1:14 O -
Ind4 SPS UC3 X1:15 O -
Ind5 SPS UC3 X1:16 O -
Ind6 SPS UC3 X1:17 O -
Ind7 SPS UC3 X1:30 O -
Ind8 SPS UC3 X1:31 O -
Ind9 SPS UC3 X1:32 O -
Ind10 SPS UC3 X1:33 O -
Settings
- - - - -
Table 42: GGIO class (GGIO4)
GGIO7 - Generic process I/O
Attribute name Attribute type Explanation M/O/E Remarks
GGIO7 - GPIO UC4 - -
Common logical node information
Mod ENC Mode O status-only
Beh INS Behavior M -
Health INS Health O 1 = OK; 3 = no in-
ternal communi-
cation
NamPlt LPL Name plate O -
Controls
- - - - -
Measured values
- - - - -
Status information
Ind1 SPS UC4 X1:11 O -
Ind2 SPS UC4 X1:12 O -
Ind3 SPS UC4 X1:14 O -
Ind4 SPS UC4 X1:15 O -
Ind5 SPS UC4 X1:16 O -
Ind6 SPS UC4 X1:17 O -
Ind7 SPS UC4 X1:30 O -
7.2.11
