7 Control system protocol
Maschinenfabrik Reinhausen 2014 1292374092/04 EN TAPCON® 260
Attribute name Attribute
type
Explanation M/O/E Remarks
PhyHealth INS Physical device health M -
Proxy SPS Indicates if this LN is a proxy M -
Table 33: LPHD class (LPHD1)
LLN0 - Logical node
Attribute name Attribute
type
Explanation M/O/E Remarks
LLN0 - Logical node zero name - -
Data
Common logical node information
Mod ENC Mode M Status only
Beh INS Behavior M -
Health INS Health M -
NamPlt LPL Name plate M -
Table 34: LLNO class
ATCC1 - Automatic tap changer controller
Attribute
name
Attribute
type
Explanation M/O/E/C Remarks
ATCC1 - AVR - -
Common logical node information
Mod ENC Mode O status-only
Beh INS Behavior M -
Health INS Health O 1:=OK; 2:=function
monitoring; 3:=no
internal communi-
cation or parame-
ter error
NamPlt LPL Name plate O -
Controls
TapChg BSC Change tap position C direct-with-normal-
security
ParOp DPC Parallel independent M direct-with-normal-
security
LTCBlk SPC Block automatic control O direct-with-normal-
security
CirCur SPC Circulating current (parallel con-
trol)
E direct-with-normal-
security
Master SPC Master mode (parallel control) E direct-with-normal-
security
7.2.2
7.2.3
