3 Product description
Maschinenfabrik Reinhausen 201416 2374092/04 ENTAPCON® 260
Local mode (LOCAL)
There is no active management by a superordinate control system in this op-
erating mode.
Remote mode (REMOTE)
In remote mode, you can perform commands using an external control level.
In this case, manual operation of the , , and keys is disa-
bled.
+
LOCAL
+
REMOTE
+
LOCAL
+
REMOTE
Automatic regulation Yes Yes No No
Tap-change operation
using operating controls
No No Yes No
Tap-change operation
using inputs
No No No Yes
Tap-change operation
using SCADA*
No No No Yes
Value adjustment using
SCADA*
No Yes No Yes
Table 4: Overview of operating modes
*) Optional when connecting TAPCON® to a control system (SCADA)
Hardware
The individual assemblies are fitted in a standardized 19-inch plug-in hous-
ing. The front panels of the assemblies are secured to the plug-in housing at
the top and bottom. An IEC 60603-2 plug connector provides the electrical
connection.
The assemblies are connected to one another via a data bus and direct cur-
rent (DC) supply. This allows for an upgrade with additional plug-in modules
and extension cards at a later date.
3.5
