MR TAPCON 260 - ATCC1 Parameters for Compensation and Blocking; ATCC1 Compensation Parameters (LDCX, BlkLV)

7 Control system protocol
Maschinenfabrik Reinhausen 2014 1312374092/04 EN TAPCON® 260
Attribute
name
Attribute
type
Explanation M/O/E/C Remarks
LDCX ASG Line drop voltage due to line re-
actance component (voltage)
O Unit: V
Multiplier: none
BlkLV ASG Control voltage below which au-
to lower commands blocked
(relative)
O Unit: none
Multiplier: c
LimLodA ASG Limit load current (LTC block
load current, percentage)
O Unit: none
Multiplier: c
LDC SPG Line drop compensation is R
and X or Z model (0=R and X,
1=Z compensation)
O -
TmDlChr SPG Time delay linear or inverse
characteristic (0=lin., 1=inv.)
O -
LDCZ SPG Line drop voltage due to line to-
tal impedance (percentage of
nominal voltage)
O Unit: none
Multiplier: c
TapBlkR ING Tap position of on-load tap
changer where automatic raise
commands are blocked
O -
TapBlkL ING Tap position of on-load tap
changer where automatic lower
commands are blocked
O -
Table 35: ATCC class (ATCC1)
YLTC1
Attribute name Attribute type Explanation M/O/E Remarks
YLTC1 - OLTC - -
Common logical node information
Mod INC Mode O status only
Beh INS Behavior M -
Health INS Health O 1 = OK; 2 = signaling
YELLOW for
TAPGUARD; 3 = no
internal communica-
tion of parameter error
or signaling RED for
TAPGUARD
NamPlt LPL Name plate O
Controls
TapChg BSC Change tap position C direct with normal se-
curity
Measured values
- - - - -
Status information
7.2.4
