7 Control system protocol
Maschinenfabrik Reinhausen 2014132 2374092/04 ENTAPCON® 260
Attribute name Attribute type Explanation M/O/E Remarks
EndPosR SPS End position raise
reached
M -
EndPosL SPS End position lower
reached
M -
Settings
- - - - -
Table 36: YLTC class
YLTC2
Attribute name Attribute type Explanation M/O/E Remarks
YLTC2 - OLTC - -
Common logical node information
Mod INC Mode O status only
Beh INS Behavior M -
Health INS Health O 1 = OK; 2 = signaling
YELLOW for
TAPGUARD; 3 = no
internal communica-
tion of parameter error
or signaling RED for
TAPGUARD
NamPlt LPL Name plate O
Controls
TapChg BSC Change tap position C direct with normal se-
curity
Measured values
- - - - -
Status information
EndPosR SPS End position raise
reached
M -
EndPosL SPS End position lower
reached
M -
Settings
- - - - -
Table 37: YLTC class
YLTC3
Attribute name Attribute type Explanation M/O/E Remarks
YLTC3 - OLTC - -
Common logical node information
Mod INC Mode O status only
7.2.5
7.2.6
