Maschinenfabrik Reinhausen 2014 1452374092/04 EN TAPCON® 260
Relay Inscription Cause
IO-X1:20 UNDERVOLT-
AGE
OVERVOLTAGE
OVERCURRENT
Signal for undervoltage, overvoltage,
overcurrent message
IO-X1:23 PARALLEL
FAULT, or: See
connection dia-
gram
Signal for parallel operation error mes-
sage
IO-X1:25 PARALLEL ON,
or: See connec-
tion diagram
Signal if parallel operation is active
UC-
X1:06...10,
UC-
X1:19...23
TAP POSITION
BCD1…BCD20
BCD signal of tap position
IO-X1:2/3 STATUS Operating relay
UC1/2/3-
X1:02
ED1/2/3 LOWER Lower tap position of motor-drive unit
ED1/2/3
UC1/2/3-
X1:04
ED1/2/3 RAISE Raise tap position of motor-drive unit
ED1/2/3
Table 51: Signal outputs
Event messages
Event message Cause
Undervoltage Event message appears if value falls below un-
dervoltage limit value.
Overvoltage Event message appears if value exceeds over-
voltage limit value.
Overcurrent Event message appears if value exceeds over-
current limit value.
