3 Product description
Maschinenfabrik Reinhausen 2014 172374092/04 EN TAPCON® 260
Figure 2: Front view
1 Operating panel with display
and LEDs
3 19-inch plug-in housing (in ac-
cordance with DIN 41494 Part
5)
2 Rack for optional expansions 4 Name plate
Name plate
The name plate is on the outside of the device:
Figure 3: Name plate
Operating controls
The device has 15 pushbuttons. The illustration below is an overview of all
the device's operating controls .
3.5.1
3.5.2
