7 Control system protocol
Maschinenfabrik Reinhausen 2014130 2374092/04 ENTAPCON® 260
Attribute
name
Attribute
type
Explanation M/O/E/C Remarks
Follower SPC Follower mode (parallel control) E direct-with-normal-
security
SICmd1 SPC Serial interface command 1 E direct-with-normal-
security
SICmd2 SPC Serial interface command 2 E direct-with-normal-
security
SICmd3 SPC Serial interface command 3 E direct-with-normal-
security
VoltLvl1 SPC Voltage level 1 E direct-with-normal-
security
VoltLvl2 SPC Voltage level 2 E direct-with-normal-
security
VoltLvl3 SPC Voltage level 3 E direct-with-normal-
security
Measured values
CtlV MV Control voltage M Unit: V
Multiplier: none
LodA MV Load current (transformer sec-
ondary current)
O Unit: A
Multiplier: none
Status information
Loc SPS Local operation M -
Auto SPS Automatic manual O -
OverV SPS Voltage high limit reached E -
UnderV SPS Voltage low limit reached E -
OverC SPS Current overload E -
MotDrv SPS Motor drive running E -
UInd1 SPS User indication 1 E -
UInd2 SPS User indication 2 E -
UInd3 SPS User indication 3 E -
UInd4 SPS User indication 4 E -
FuncMon SPS Function monitoring E -
ParErr SPS Parameter error E -
Settings
BndCtr ASG Band center voltage (actual ref-
erence)
O Unit: V
Multiplier: none
BndWid ASG Band width voltage (as percent
of nominal voltage, FPF pre-
sumed)
O Unit: none
Multiplier: c
CtlDlTmms ING Control intentional time delay
(FPF presumed, in seconds)
O -
LDCR ASG Line drop voltage due to line re-
sistance component (voltage)
O Unit: V
Multiplier: none
